Low frequency transformer is used to spread the signal voltage and signal power, but also can realize the impedance matching between circuits, and has the isolation effect on DC. High-frequency transformer and low-frequency transformer principle is no difference. However, due to the different frequencies of high frequency and low frequency, the core used in the transformer is different. Low-frequency transformers generally use high permeability silicon steel sheet, high-frequency transformer with high-frequency ferrite core.
It is divided into interstage coupling transformer, input transformer and output transformer, the shape are similar to the power transformer.
1. Inter-pole coupling transformer: inter-stage coupling transformer used between the two audio amplification circuits, as a coupling element, the output signal of the former amplification circuit is transmitted to the latter, and make the appropriate impedance transformation.
2. Input transformer: in the early semiconductor radio, audio push stage and power amplifier stage between the transformer used for the input transformer, signal coupling, transmission, also known as the push transformer.
Input transformers are single-ended and push-pull. If the driving circuit is a single-ended circuit, the input transformer is also a single-ended input transformer; if the driving circuit is a push-pull circuit, the input transformer is also a push-pull input transformer.
3. Output transformer: output transformer connected to the output circuit of the power amplifier and the speaker between the main signal transmission and impedance matching role. Output transformer is also divided into single-ended output transformer and push-pull output transformer two kinds.
Characteristics of low frequency transformer
1. Since the calculated capacity of the LV transformer is less than the rated capacity. Therefore, for the same rated capacity, the main dimensions of the LV transformer are smaller, and the effective materials (silicon steel sheets and wires) and structural materials (steel) are reduced accordingly, thus reducing the cost. Along with the reduction of effective materials, the consumption of copper and iron is also reduced accordingly, so the LV transformer works efficiently. In addition, because of the smaller key specifications and reduced quality, a single delivery standard enables the production and manufacture of LV transformers with a larger volume under the permissible delivery standard. However, the above advantages are usually obvious only when k≤2 in low frequency transformers.
2.Because low-frequency transformer modules have a higher short-circuit impedance than double-wound resistance.
Over-current protection, over-voltage protection, overload protection, lightning protection, short-circuit protection, voltage regulator protection
What factors impact high-frequency transformers' lifespan?
High-frequency transformer lifespan can be impacted by a variety of factors, including:
- Operating temperature: High operating temperatures can accelerate the aging and breakdown of the insulation materials, resulting in reduced transformer life. Rapid temperature changes can also cause thermal stress and transformer mechanical failure.
- Electrical stress: High-frequency transformers can be subject to electrical stress from high voltage and high-frequency currents. This can lead to the breakdown of insulation materials and result in partial discharge, which can cause further degradation of the insulation and reduce transformer life.
- Environmental factors: The transformer's operating environment can also have an impact on its lifespan. Exposure to moisture, dust, and other contaminants can cause corrosion, electrical leakage, and other issues that reduce transformer life.
- Mechanical stress: Mechanical stress, such as vibration or shock, can also impact high-frequency transformer lifespan. This can lead to mechanical failure or loosening of components, resulting in short circuits or insulation breakdown.
- Manufacturing quality: The quality of materials, construction, and manufacturing processes can also impact high-frequency transformer lifespan. Poor quality materials or manufacturing practices can result in manufacturing defects, which can cause transformer failure or reduce its useful life.
- Load management: Improper load management can cause the transformer to operate outside of its specified operating range, which can cause overheating, insulation breakdown, and other issues that can reduce the transformer's lifespan.
- Maintenance: Regular maintenance, testing, and inspection are important for identifying and addressing any potential issues before they become critical and affect the transformer's lifespan.
Advantages of multiple parallel windlings for low frequency transformers
1. Improving efficiency
Low-frequency transformers with multiple parallel windings can reduce the permeability loss and copper loss. Conductive loss is due to the core magnetization and flux changes caused by the loss, and copper loss is due to the current through the winding when the heat caused by the loss. Multi-wire parallel winding can reduce the current of each wire, thereby reducing copper losses; at the same time, this design can also reduce the intensity of the magnetic field induced in the winding, thereby reducing the permeability loss. Therefore, low-frequency transformers with multiple parallel windings can improve the efficiency of the transformer.
Low frequency transformers are characterized by high efficiency and energy saving. Low frequency transformers are very important equipment in the process of power transmission and distribution. Low-frequency transformers can convert high voltage into low voltage, so that the power becomes more suitable and easy to transmit. At the same time, low-frequency transformers can also reduce the loss of electrical energy, thus realizing the effect of high efficiency and energy saving. Therefore, low-frequency transformers have great advantages in terms of energy consumption and environmental protection.
Low frequency transformers are characterized by low noise. In many industrial and living occasions, the noise of the equipment may cause great disturbance to people. The internal structure and material selection of low-frequency transformers can effectively reduce the noise generated by the equipment. At the same time, due to the low-frequency transformer internal operation mechanism is relatively simple, the noise during operation is also relatively low, thus ensuring the quiet and stable operation of the equipment.
2. Increasing power density
Multi-wire parallel winding of low frequency transformers increases the surface area of the windings, thus increasing the power density of the transformer. This means that a transformer with multiple parallel windings can provide greater power output for the same size. This is especially important for applications where space is limited.
Low-frequency transformers are characterized by their compactness. Because the internal structure of low-frequency transformers is relatively simple, with fewer component components, low-frequency transformers can be designed to be relatively small in size and easy to handle and install. In some occasions where space is limited, low-frequency transformers can effectively solve the problem of space constraints during the installation of equipment, so as to better meet the needs of users.
Low frequency transformers are characterized by low cost. Compared with some other power equipment, low-frequency transformer manufacturing cost is relatively low. And because of the low frequency transformer's high reliability, long life, low maintenance costs and other advantages, so that its overall cost in the actual application process is also lower than other equipment. Therefore, low-frequency transformers have very great advantages in terms of economy.
3. Reducing temperature rise
Multiple parallel windings of low frequency transformers reduce the current density in the windings, thereby reducing the temperature rise inside the windings. This helps to protect the windings and prevent insulation deterioration, thereby extending the life of the transformer.
